Curing Pen E – Brilliant Illumination for Superior Performance
360° Rotating Head
– Designed to rotate fully, allowing effortless access to different treatment angles and areas.
Compact Light Tip
– Slim tip design makes it easier to reach posterior molars, improving comfort and overall patient experience.
High Power Output
– Delivers light intensity up to 3000 mw/cm².
– Strong output supports deeper curing depth, helping resins set faster and more effectively.
Advanced Lens Structure
– Specially engineered lens creates a focused and consistent light beam to ensure uniform curing results.
Wide Spectral Coverage (380–515 nm)
– Why is a broad spectrum important?
– Many dental resins rely on camphorquinone (CQ) as an initiator. However, some materials use alternatives like TPO to minimize yellow discoloration associated with CQ. TPO activates only under wavelengths below 410 nm. Thanks to its extended spectral range, Curing Pen E efficiently cures various types of resin materials.
Technical Specifications – Curing Pen E
-
Dimensions: 19 × 16.5 × 7.5 cm
-
Weight: 120 g
-
Lens Diameter: 8 mm
-
Power Capacity: Over 1200 cycles at 3000 mw/cm² for 3 seconds
-
Maximum Light Intensity: 3000 mw/cm²
-
Spectral Range: 380–515 nm
